LINK Wireless Kamera Cloud beltéri éjjellátó, VIGI C400HP-4 VIGI C400HP-4 VIGI C400HP-4(UN)
- Gyártó: TP-LINK
- Microstore cikkszám:
- Gyári szám: VIGI C400HP-4(UN)
- Garancia: 24 hónap
- Készlet információ:
Mai rendelés esetén
🏪 Átvétel üzletünkben (Vecsés): júl. 15. (szerda)
🚚 Házhozszállítás: júl. 16. (csütörtök)
📦 FoxPost csomagautomata: júl. 17. (péntek)
-
27 832 Ft
-
Nettó: 21 915 Ft
💡 Jó tudni: üzletünkben azonnal a „Raktáron” jelzésű termékek vehetők át, a többit rendelésére szerezzük be: az „1–2” és „2–3 munkanap” jelzésűek hazai raktárból érkeznek, a „3–14 nap” jelzésűek pedig általában külföldi partnereinktől — ezért hosszabb a beszerzési idejük. Amint a termék átvehető, értesítjük. Személyes átvétel előtt kérjük, várja meg ezt az értesítést, hogy biztosan ne jöjjön hiába — ha pedig sürgős, keressen minket bizalommal, szívesen segítünk!
Security
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Protocol
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
API
ONVIF
Simultaneous Live View
4 Main Streams & 3 Sub-Streams,
or 3 Main Streams & 5 Sub-Streams
GENERAL
Certification
CE, FCC, RCM, BSMI, VCCI, IP67, RoHS
Dimensions( H X W X D )
123 × 123 × 83 mm
Materia
Plastic
Weight
195 g
Power Requirements
12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3af/at, class 0)
General Features
Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
CAMERA
Image Sensor
1/2.7” Progressive Scan CMOS
Lens
4 mm / 2.8 mm
Aperture
4 mm: F2.4
2.8 mm: F2.0
Lens Mount
M12
Viewing Angle
4 mm, horizontal FOV: 92°, vertical FOV: 48°, diagonal FOV: 114°
2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 125°
Day/Night Mechanism
IR Cut Filter
IR Working Distance
30m
Minimum Illumination
Color: 0.1 Lux@F2.0, 0 Lux with IR
Pan/Tilt Range
Pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360°
Digital Noise Reduction
3D DNR
WDR
DWDR
VIDEO/IMAGE
Video Compression
Main stream: H.265/H.264
Sub-Stream: H.265/H.264
Frame Rate & Resolutions
Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720, 704x576, 640x480, 352x288, 320x240
Image Enhancement
BLC/3D DNR/Prevent Overexposure to Infrared Light
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Video Bit Rate
64 Kbps to 6 Mbps
SMART FEATURE-SET
Smart Event
Area Intrusion Detection, Line-Crossing Detection
Basic Event
Motion Detection, Video Tampering Detection, Exception ( illegal login)
Linkage Method
Trigger Notification: ONVIF, HTTPS
Region of Interest
1 Region
INTERFACES
Network Interface
1 RJ45 10/100M Self-Adaptive Ethernet Port
Button
-
Video Output
-
VIGI C400HP-4 KSH szám: 8525801990
