STARTECH 4 PORT GIGABIT POE PCIE NIC ST4000PEXPSE
- Gyártó: STARTECH
- Microstore cikkszám:
- Gyári szám: ST4000PEXPSE
- Garancia: 24 hónap
- Készlet információ:
Mai rendelés esetén
🏪 Átvétel üzletünkben (Vecsés): aug. 5. (szerda)
🚚 Házhozszállítás: aug. 6. (csütörtök)
📦 FoxPost csomagautomata: aug. 7. (péntek)
-
148 422 Ft
-
Nettó: 116 868 Ft
💡 Jó tudni: üzletünkben azonnal a „Raktáron” jelzésű termékek vehetők át, a többit rendelésére szerezzük be: az „1–2” és „2–3 munkanap” jelzésűek hazai raktárból érkeznek, a „3–14 nap” jelzésűek pedig általában külföldi partnereinktől — ezért hosszabb a beszerzési idejük. Amint a termék átvehető, értesítjük. Személyes átvétel előtt kérjük, várja meg ezt az értesítést, hogy biztosan ne jöjjön hiába — ha pedig sürgős, keressen minket bizalommal, szívesen segítünk!
The ST4000PEXPSE 4-Port PoE NIC lets you add four Gigabit Power over Ethernet ports through a single PCI Express slot. Each port can provide up to 25.5W of power, combining network data and power over a single Ethernet cable for reduced cable clutter and added convenience for remote PoE devices.
The PCI express PoE card supports the IEEE 802.3at (Type 1 and 2) standard for Power Sourcing Equipment (PSE), and can deliver up to 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and data connection for PoE devices such as IP cameras, IP phones or wireless access points.
Suitable for any standard profile PCIe-enabled client, server or workstation, the PoE network card supports features such as Jumbo Frames (up to 9KB), VLAN tagging and Wake on LAN (WoL).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
Position your network devices where power outlets aren’t available, with 25.5 Watts per-port PoE output
Reduce expenses by using existing standard Cat5 (or better) Ethernet cabling to deliver power and data
Optimize network traffic with support for advanced features, like Jumbo Frames and VLAN tagging
Bus Type
PCI Express
Card Type
Standard Profile
Chipset ID
Realtek - RTL8111E
Industry Standards
IEEE 802.3at, 802.3af, 802.3, 802.3u, 802.3ab, 802.3az Draft 2.2 Energy-Efficient Ethernet (EEE), 802.1q VLAN tagging, 802.1p Layer 2 Priority Encoding and 802.3x Full Duplex Flow Control
Interface
RJ45 (Gigabit Ethernet)
Port Style
Integrated on Card
Ports
4
Performance
Auto MDIX
Yes
Buffer Size
48 KB
Compatible Networks
10/100/1000 Mbps
Full Duplex Support
Yes
Jumbo Frame Support
9K max.
Maximum Data Transfer Rate
2000 Mbps (Full-duplex)
Connector(s)
Connector Type(s)
1 - PCI Express x4 Male
External Ports
4 - RJ-45 Female
Internal Ports
1 - LP4 (4 pin; Molex Large Drive Power) Male
1 - SATA Power (15 pin) Plug
Software
OS Compatibility
Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista(32/64), XP(32/64)Windows Server® 2012, 2008 R2, 2003(32/64)Linux 2.4.x and later
Special Notes / Requirements
Patents and Licenses
The following patents are licensed for this product. This list might not be all inclusive.• United States Patent No. 5,406,260 (expired)• United States Patent No. 6,650,622• United States Patent No. 7,457,250• United States Patent No. 8,155,012• United States Patent No. 8,902,760• United States Patent No. 8,942,107• United States Patent No. 9,019,838• United States Patent No. 9,049,019• United States Patent Application No. 14/695,456• United States Patent Application No. 14/726,940
System and Cable Requirements
Available full height (standard profile) PCI Express expansion slot
Available LP4 Molex or SATA power connector
Indicators
LED Indicators
4 - Link/ Activity (green)
4 - PoE Active (yellow)
Power
Output Voltage
48 DC
Environmental
Humidity
10~90% RH (Non-condensing)
Operating Temperature
0°C to 55°C (32°F to 131°F)
Storage Temperature
-40°C to 75°C (-40°F to 158°F)
Physical Characteristics
Product Height
4.7 in [120 mm]
Product Length
9.6 in [243 mm]
Product Weight
3.6 oz [102 g]
Product Width
0.7 in [18 mm]
Packaging Information
Shipping (Package) Weight
15.1 oz [428 g]
What's in the Box
Included in Package
1 - PCI Express Network Card
1 - Driver CD
1 - Instruction Manual
