Model Name

4G-AX56



Network Standard

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6



Product Segment

AX1800 ultimate AX performance



Data Rate

802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps



Connectivity Technology

LTE: Downlink 300 Mbps / Uplink 50 Mbps
HSPA+: Downlink 42 Mbps / Uplink 11 Mbps
4G FDD-LTE: 2100 /1800 /850 /2600 /900 /800 /700
4G TDD-LTE: 2300 /2600 /2500
3G UMTS: 2100 /1800 /850 /900



Antenna

WiFi: 2 x external fixed antenna
LTE: 1 x external fixed antenna, 1 x internal antenna



Memory

128 MB Flash
512 MB RAM



Operating Frequency

2.4 GHz / 5 GHz



Ports

1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot



Button

Power, Reset, WPS



LED Indicator

Power x 1
WiFi x 2
WAN x 1
Mobile WAN connection x 1
Mobile WAN signal x 3



Package content

4G-AX56
Quick Start Guide
Warranty Card
RJ45 Cable
Power Adapter



Product Weight (g)

753



AiMesh

AiMesh : No
Primary AiMesh router : No
AiMesh node : No



Router APP

ASUS Router APP : Yes



Game

Game Boost/acceleration : No
WTFast : No



Alexa

Support Alexa skill : Yes



IFTTT

Support IFTTT : No



AiProtection

AiProtection : AiProtection Classic
Router Security Assessment : Yes
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : No



Parental Control

Parental Control : Yes
Parental Control Customized Internet schedule : Yes



Traffic Control

Adaptive QoS : No
Bandwidth Monitor : No
Bandwidth limiter : Yes
Traditional QoS : Yes
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Traffic Analyzer : No
Website history : Yes



Wireless

IPv6 : Yes
MU-MIMO : Yes
UTF-8 SSID : Yes
Guest Network : Yes
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : Yes
Wireless scheduler : Yes
Airtime fairness : Yes
RADIUS Server : No
Universal beamforming : Yes
Explicit beamforming : Yes



WAN

Internet connection Type : Mobile WAN, Ethernet WAN
Dual WAN : Yes
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : No
Port forwarding : Yes
Port triggering : No
DMZ : Yes
DDNS : Yes
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Let's Encrypt : Yes



LAN

DHCP Server : Yes
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64



VPN

VPN Client L2PT : Yes
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : No
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No



USB application

File System : No
HDD hibernation : No
Safely Remove disk : No
AiCloud : No
Download master : No
Media Server : No
AiDisk : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No



Administration

Operating mode : Modem Router,Access Point
Operating system : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
Configuration backup and restore : Yes
SSH : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes

4G-AX56 KSH szám: 8517620000
