EATON 3S Gen2 850VA UPS 9400-A303
- Gyártó: EATON
- Microstore cikkszám:
- Gyári szám: 9400-A303
- Garancia: 24 hónap
- Készlet információ:
Mai rendelés esetén
🏪 Átvétel üzletünkben (Vecsés): szept. 16. (szerda)
🚚 Házhozszállítás: szept. 17. (csütörtök)
📦 FoxPost csomagautomata: szept. 18. (péntek)
-
59 959 Ft
-
Nettó: 47 212 Ft
💡 Jó tudni: üzletünkben azonnal a „Raktáron” jelzésű termékek vehetők át, a többit rendelésére szerezzük be: az „1–2” és „2–3 munkanap” jelzésűek hazai raktárból érkeznek, a „3–14 nap” jelzésűek pedig általában külföldi partnereinktől — ezért hosszabb a beszerzési idejük. Amint a termék átvehető, értesítjük. Személyes átvétel előtt kérjük, várja meg ezt az értesítést, hogy biztosan ne jöjjön hiába — ha pedig sürgős, keressen minket bizalommal, szívesen segítünk!
Garancia: 2 Év
General specifications
Product Name
Eaton 3S Gen2 UPS
Catalog Number
3S850D
UPC
743172101778
Product Length/Depth
83.5 mm
Product Height
170 mm
Product Width
335 mm
Product Weight
4.2 kg
Compliances
CE Marked
Certifications
EAC
IEC/EN 62040-2
CE
IEC/EN 62040-1
Additional information
Construction type
Free standing model
Package contents
USB cable
Quickstart guide
Safety instructions
Phase (output)
1
Auto shutdown function
Yes
Color
Black/White
Efficiency at max. load
98
Rack mounting kit
No
Phase (input)
1
Surge protection
Yes
Battery
Battery type
Sealed, lead-acid
Runtime graph
View runtime graph
Battery replacement
User replaceable
Battery quantity
1
Battery management
Replaceable batteries, Automatic battery test, deep-discharge protection, cold-start capable
Battery rating
12 V / 9 Ah
Extended battery capability
No
Communication
Includes network card
No
Communication
USB port (HID compliant)
Ethernet interface
No
User interface
LEDs
Potential free switch contact
No
Expansion slots
No
Software compatibility
Eaton UPS Companion (enables safe system shutdown, energy usage metering and configuration of UPS settings)
Type of interface
USB
Electrical input
Input connection
Other
Input nominal voltage
230V default (220/230/240V)
Nominal frequency
50/60 Hz
Input cord length
1.5 m
Input voltage range
184-264 V (adjustable to 161-284 V)
Input frequency range
46-70 Hz
Electrical output
Receptacle
(4) Schuko, (4) Schuko surge only
Voltage
230V
Wattage
510W
Output power factor
0.6
Output voltage range
184-264 V (adjustable to 161-284 V)
Output nominal voltage
230V default (220/230/240V)
Voltage distortion output (linear load) - max
0
Feed type
1
Topology
Offline
VA rating
850 VA
Environmental
Altitude
2000 m
Noise level
<25 dB at 1 meter
Relative humidity
0-85% non-condensing
