DJI Mavic 3 Classic (DJI RC) CP.MA.00000555.01

DJI Mavic 3 Classic (DJI RC)








In the Box







DJI Mavic 3 Classic x1

DJI Mavic 3 Intelligent Flight Battery x1

DJI RC x1

DJI Mavic 3 Low-Noise Propellers (pair) x3

DJI 65W Portable Charger x1

USB-C Cable x1

DJI Mavic 3 Classic Storage Cover x1

Spare DJI RC Control Sticks (pair) x1
.










Specs





DJI Mavic 3 Classic





Aircraft







Takeoff Weight: 895 g

Dimensions:

Folded (without propellers): 221×96.3×90.3 mm (L×W×H)
Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)

Max Ascent Speed: 8 m/s

Max Descent Speed: 6 m/s

Max Horizontal Speed (at sea level, no wind): 21 m/s

No faster than 19 m/s in EU regions.

Max Takeoff Altitude: 6000 m

Max Flight Time: 46 minutes

Measured in a controlled test environment. Specific test conditions are as follows: flying at a constant speed of 32.4 kph in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

Max Hovering Time: 40 minutes

Measured in a controlled test environment. Specific test conditions are as follows: hovering in a windless environment at sea level, with APAS off, AirSense off, camera parameters set to 1080p/24fps, video mode off, and from 100% battery level until 0%. Results may vary depending on environment, actual use, and firmware version.

Max Flight Distance: 30 km

Max Wind Speed Resistance: 12 m/s

Max Tilt Angle: 35°

Operating Temperature: -10° to 40° C (14° to 104° F)

Global Navigation Satellite System: GPS + Galileo + BeiDou

Hovering Accuracy Range:

Vertical:
±0.1 m (with vision positioning)
±0.5 m (with GNSS positioning)

Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with high-precision positioning system)

Internal Storage: 8 GB (approx. 7.9GB available space)
.










Hasselblad Camera







Image Sensor: 4/3 CMOS, Effective Pixels: 20 MP

Lens:

FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8-f/11
Focus: 1 m to ∞

ISO Range:

Video:
Normal, Slow-motion:
100-6400 (normal color)
400-1600 (D-Log)
100-1600 (HLG)
Night Mode:
800-12800 (normal color)

Photo:
100-6400

Shutter Speed: Electronic Shutter: 8-1/8000 s

Max Image Size: 5280×3956

Still Photography Modes:

Single Shot: 20 MP
Burst Shooting: 20 MP, 3/5/7 frames
Automatic Exposure Bracketing (AEB): 20 MP, 3/5 frames at 0.7 EV step
Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s

Photo Format: JPEG/DNG (RAW)

Video Resolution:

H.264/H.265
5.1K: 5120×2700@24/25/30/48/50 fps
DCI 4K: 4096×2160@24/25/30/48/50/60/120* fps
4K: 3840×2160@24/25/30/48/50/60/120* fps
FHD: 1920×1080@24/25/30/48/50/60/120*/200* fps

* Recording frame rates. The corresponding video plays as slow-motion video.

Video Format: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)

Max Video Bitrate: H.264/H.265: 200 Mbps

Supported File System: exFAT

Color Mode: Normal/HLG/D-Log

Digital Zoom: 3×
.










Gimbal







Stabilization: 3-axis mechanical gimbal (tilt, roll, pan)

Mechanical Range:

Tilt: -135° to 100°
Roll: -45° to 45°
Pan: -27° to 27°

Controllable Range:

Tilt: -90° to 35°
Pan: -5° to 5°

Max Control Speed (tilt): 100°/s

Angular Vibration Range: ±0.007°
.










Sensing







Sensing Type: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft

Forward:

Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 103°

Backward:

Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed ≤ 12 m/s
FOV: Horizontal 90°, Vertical 103°

Lateral:

Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 85°

Upward:

Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 100°, Left and Right 90°

Downward:

Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 130°, Left and Right 160°

Operating Environment:

Forward, Backward, Left, Right, and Upward: surfaces with discernible patterns and adequate lighting (lux >15)
Downward: surfaces with discernible patterns, diffuse reflectivity >20% (e.g. walls, trees, people), and adequate lighting (lux >15)
.










Video Transmission







Video Transmission System: O3+

Live View Quality:

Remote Controller: 1080p/30fps, 1080p/60fps

Operating Frequency:

2.400-2.4835 GHz
5.725-5.850 GHz

Transmission Power (EIRP):

2.400-2.4835 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)

5.725-5.850 GHz:
< 33 dBm (FCC)
< 30 dBm (SRRC)
< 14 dBm (CE):

Max Transmission Distance (free of interference):

FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km

Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminders in the DJI Fly app.

Max Transmission Distance (with interference):

Strong Interference: urban landscape, approx. 1.5-3 km
Medium Interference: suburban landscape, approx. 3-9 km
Low Interference: suburb/seaside, approx. 9-15 km

Data tested under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual flight distance.

Max Download Speed:

O3+:
5.5 MB/s (with DJI RC-N1 Remote Controller)
15 MB/s (with DJI RC Pro)
5.5 MB/s (with DJI RC)

Wi-Fi 6: 80 MB/s*

* Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, with footage saved to the internal storage. Download speeds may vary depending on the actual conditions.

Lowest Latency:

130 ms (with DJI RC-N1 Remote Controller)
120 ms (with DJI RC Pro)
130 ms (with DJI RC)

Depending on the actual environment and mobile device.

Antennas: 4 antennas, 2T4R
.










Battery







Capacity: 5000 mAh

Weight: 335.5 g

Nominal Voltage: 15.4 V

Charging Voltage Limit: 17.6 V

Type: Li-ion 4S

Energy: 77 Wh

Charging Temperature: 5° to 40° C (41° to 104° F)

Charging Time: Approx. 96 minutes

Use the included data cable of the DJI 65W Portable Charger.

.










Charger







Input: 100-240 V (AC), 47-63 Hz, 2 A

Output:

USB-C:
5 V, 5 A
9 V, 5 A
12 V, 5 A
15 V, 4.3 A
20 V, 3.25 A
5-20 V, 3.25 A

USB-A:
5 V, 2 A

Rated Power: 65 W
.










Battery Charging Hub







Input: USB-C: 5-20 V, max 5 A

Output: Battery Port: 12-17.6 V, max. 5 A

Rated Power:

DJI Mavic 3 Battery Charging Hub: 65 W
DJI Mavic 3 Battery Charging Hub (100W): 100 W

Charging Type: Three batteries charged in sequence

Compatibility: DJI Mavic 3 Intelligent Flight Battery
.










Storage







Recommended microSD Cards:

Lexar 1066x 64GB V30 A2 microSDXC
Lexar 1066x 128GB V30 A2 microSDXC
Lexar 1066x 256GB V30 A2 microSDXC
Lexar 1066x 512GB V30 A2 microSDXC

SanDisk High Endurance 64GB V30 microSDXC
SanDisk High Endurance 128GB V30 microSDXC
SanDisk High Endurance 256GB V30 microSDXC

Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas Go! Plus 256GB V30 A2 microSDXC
Kingston Canvas Go! Plus 512GB V30 A2 microSDXC

Samsung EVO Plus 512GB V30 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC
Samsung PRO Plus 512GB V30 A2 microSDXC
.










Remote Controller







Max Operating Time:

DJI RC-N1 Remote Controller
Without charging any mobile device: 6 hours
When charging a mobile device: 4 hours

Max Supported Mobile Device Size

DJI RC-N1 Remote Controller
180×86×10 mm (L×W×H)

Operating Temperature:

DJI RC-N1 Remote Controller
-10° to 40° C (14° to 104° F)

Transmitter Power (EIRP):

DJI RC-N1 Remote Controller
2.400-2.4835 GHz:
< 26 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)


5.725-5.850 GHz:
< 26 dBm (FCC)
< 23 dBm (SRRC)
< 14 dBm (CE)
.
